X20CP1586 B&R CPU Units module in stock

X20CP1586 Communication Interfaces

Ethernet (IF2)

• Type:X20CP1586
• Transfer Rate: 10/100/1000 Mbit/s
• Physical Layer: 10BASE-T/100BASE-TX/1000BASE-T
• Features: Full-duplex/half-duplex support, autonegotiation, Auto-MDI/MDIX
• Max. Cable Length: 100 m per segment

POWERLINK (IF3)

• Type: X20CP1586
• Protocol: POWERLINK V1/V2 (managing or controlled node)
• Transfer Rate: 100 Mbit/s
• Physical Layer: 100BASE-TX
• Features: Autonegotiation, Auto-MDI/MDIX; full-duplex (Ethernet mode)
• Max. Cable Length: 100 m per segment

RS232 (IF1)

• Type:
• Transfer Rate: Max. 115.2 kbit/s
• Max. Distance: 900 m

USB Interfaces

• IF4: USB 1.1/2.0 Type A (max. output current: 0.5 A)
• IF5: USB 1.1/2.0 (for peripheral connection or data transfer)

System Bus

• Modular Interface Slot: 1 (supports X20 I/O modules and communication expansion modules)

Performance

• Typical Instruction Cycle Time: 0.0027 µs per boolean operation
• Shortest Task Class Cycle Time: 100 µs
• Max. I/O Expansion: Up to 8192 digital/analog I/O points (via X20 bus)
• Programming Support: IEC 61131-3 standards (Ladder Diagram, Structured Text, Function Block Diagram, etc.) – compatible with B&R Automation Studio
• Real-Time Performance: Hard real-time response, jitter ≤ 1 µs
