Fast delivery within 72 Hours

XVS-440-10MF1-1-1U EATON one year Warranty

Name: XVS-440-10MF1-1-1U EATON one year Warranty
Brand: Eaton
SKU: 1654
Availability: InStock

$432.00

Validation Protocol‌

test_reportCopy Code

1. Light/dark ratio test:

   • Light state: V_out ≥ V_supply - 1.5V @ 100mA load

   • Dark state: V_out ≤ 2V @ 100mA load

2. Ingress protection: • IP67 verification: Submerge 30min @ 1m depth → check functionality

3. Shock resistance: • 100g, 11ms half-sine pulse (IEC 60068-2-27) • Post-test drift: ≤±2% sensing distance

Add to compare

Add to wishlist

Shipping & Delivery

Courier delivery

Our courier will deliver to the specified address

2-3 Days

From $20

DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From $40

Warranty 1 year

More details

Free 30-Day returns

More details

Description

XVS Series Photoelectric Sensor Debugging Procedure‌

‌Model:‌ XVS-440-10MF1-1-1U (PNP, NO, M18 Thread, IP67)

‌Pre-Debugging Checklist‌

plaintextCopy Code

[ ] Verify power: 10-30V DC (ripple ≤10%)

[ ] Confirm wiring:

    • Brown: 24V+

    • Blue: 0V-

    • Black: Load output

    • Gray: Teach-in input

[ ] Ensure optical path clearance (no reflective surfaces <50mm)

[ ] Check ambient conditions:

    • Temperature: -25°C to +55°C

    • Humidity: ≤95% non-condensing

    • EMI shielding: ≥30dB attenuation required

‌Debugging Sequence‌

‌Step 1: Power-On Diagnostics‌

multimeterCopy Code

1. Apply voltage: Measure between Brown(+) and Blue(-) = 24V DC ±10%



2. Dark state output:

   - NO model: V_out = 0.8V max (load OFF)



3. LED indicators:

   • Green POWER: Solid = OK

   • Yellow STATUS: 1Hz blink = Operational

‌Step 2: Teach-In Mode‌

procedureCopy Code

1. Trigger teach-in:

   - Method A: Apply 5-30V DC to Gray wire for 3s

   - Method B: Use Baumer BTM 2000 programmer



2. Confirm success:

   • STATUS LED blinks 3x rapidly

   • Output toggles on object detection



3. Sensitivity adjustment:

   • Rotate pot (CW↑ sensitivity / CCW↓ sensitivity)

   • Optimal range: 40-80% of scale

‌Step 3: Dynamic Response Test‌

test_parametersCopy Code

Test Object: DIN ISO 9403 Type A (50x50mm white ceramic)

Distance: 440mm (nominal sensing range)

Speed: Variable conveyor belt (0.1-2m/s)

[Verification Metrics] • Response time: ≤1ms (dark→light transition) • Hysteresis: ≤3% of sensing distance • Repeatability: ±0.2mm @ 1kHz sampling

‌Advanced Calibration‌

‌For Challenging Surfaces (IR Mode):‌

terminalCopy Code

$ btool --device XVS440 --mode calibrate

> set_wavelength(850nm)

> set_pulse_width(200µs)

> save_config(profile3)

Requires Baumer BTools software v2.4+ and USB-IFC interface

‌Error Diagnostics‌

‌LED Pattern‌	‌Fault‌	‌Corrective Action‌
POWER off	No voltage	Check polarity & fuse (min. 100mA)
STATUS red blink (2Hz)	Saturation error	Reduce sensitivity by 25%
Both LEDs alternating	EMI interference	Install ferrite core (Z=120Ω @ 100MHz)
STATUS solid yellow	Teaching mode active	Cycle power or short gray wire to 0V
