vmf-RLC16-V111 200-570-101-015 / 200-570-000-111 Basic Technical Specifications
I. General Information

Brand: vibro-meter (a Siemens Energy brand, specialized in industrial condition monitoring and control solutions)

Product Series: vmf-RLC16-V111 Series Intelligent Digital Input/Output (I/O) Module

Model Numbers: 200-570-101-015, 200-570-000-111

Product Type: Compact, high-density digital I/O module designed for industrial control systems, integrating 16-channel configurable I/O, real-time signal processing, and reliable communication for machinery control and status monitoring

Key Applications: Control and condition monitoring of rotating equipment (turbines, generators, compressors, pumps) in power generation, oil & gas, petrochemicals, marine, and heavy industry; compatible with safety instrumented systems (SIS) and distributed control systems (DCS)

1. Core Technical Specifications(1) Power Supply Specifications

Input Voltage: 24 V DC ±10% (nominal operating voltage)

Voltage Adaptation Range: 18 V DC ~ 32 V DC (wide voltage compatibility)

Power Consumption: Typical 8 W, Maximum 12 W (full channel operation)

Reverse Polarity Protection: Built-in circuit, withstands -30 V DC reverse voltage without damage

Surge Protection: Complies with IEC 61000-4-5 standard, ±2 kV differential mode, ±4 kV common mode protection

Power Supply Ripple: ≤ 100 mVpp (within operating voltage range)

(2) Digital I/O Parameters

Common I/O Specifications for Both Models

Total Channels: 16 configurable digital channels (each channel selectable as input or output via software)

Digital Input Type: Dry contact (NO/NC configurable), PNP/NPN logic input (selectable)

Input Voltage Range: 18–30 V DC (for logic inputs)

Input Current: ≤5 mA per channel (at 24 V DC)

Input Response Time: ≤1 ms (signal edge detection)

Debounce Time: Configurable (0.1 ms ~ 100 ms)

Digital Output Type: Relay outputs (Form C, changeover contact)

Output Contact Rating: 2 A @ 250 V AC; 2 A @ 30 V DC (resistive load)

Maximum Switching Voltage: 250 V AC / 30 V DC

Maximum Switching Current: 3 A (peak, non-continuous)

Model-Specific I/O Differences

200-570-101-015: Supports high-speed digital output (switching time ≤5 ms) and channel grouping (4-channel groups for synchronous control)

200-570-000-111: Supports output channel redundancy (1:1 hot standby) and forced output function (for safety-critical applications)

(3) Communication Specifications

Communication Interfaces:

Primary: Ethernet (RJ45, 10/100 Mbps), supports PROFINET IO, Ethernet/IP, Modbus TCP

Secondary: RS485 serial port (terminal block), supports Modbus RTU (9600–115200 bps configurable)

Data Transfer Rate: Up to 100 Mbps (Ethernet); 115200 bps (max for Modbus RTU)

Communication Protocol Compliance: IEC 61158 (PROFINET), IEEE 802.3 (Ethernet), Modbus TCP/RTU v1.1

Network Redundancy: Supports PROFINET Media Redundancy Protocol (MRP) and Modbus RTU master/slave redundancy

(4) Control & Diagnostic Performance

Output Switching Time: ≤10 ms (standard); ≤5 ms (high-speed mode, 200-570-101-015 only)

Diagnostic Coverage: ≥99% (channel-level fault detection: open/short circuit, overload, communication failure)

Self-Test Function: Built-in power-on self-test (POST) and continuous loopback testing

Fault Logging: Stores up to 500 fault events with time stamps (non-volatile memory)

Synchronization Accuracy: ±1 ms (for multi-module synchronous I/O operations)

III. Dimensions & Weight

(1) Overall Dimensions (L × W × H, excluding connectors)

200-570-101-015: 110 mm × 32 mm × 125 mm (4.33 in × 1.26 in × 4.92 in)

200-570-000-111: 115 mm × 32 mm × 125 mm (4.53 in × 1.26 in × 4.92 in)

(2) Mounting Parameters

Mounting Method: 35 mm standard DIN rail mounting (complies with EN 60715:2001, TS35 standard)

Module Thickness: 1 standard DIN rail unit (32 mm)

Mounting Torque: Recommended 2.0–2.5 N·m (for terminal connections)

Connector Type: Removable spring-clamp terminals (accepts 0.5–2.5 mm² solid/stranded wire)

(3) Weight

200-570-101-015: Approximately 280 g (0.62 lb)
200-570-000-111: Approximately 300 g (0.66 lb)
