vmf-IOC16T 200-565-101-013 Vibro-meter new in stock

vmf-IOC16T 200-565-101-013  Basic Technical Specifications

1. General Information

Brand: Bosch Rexroth

Product Series: vmf-IOC16T Series Electronic Pressure Control Module

Model Numbers: 200-565-101-013

Product Type: Compact electronic control module dedicated for proportional pressure control valves, core function for precise regulation and closed-loop control of hydraulic system pressure

Key Applications: Pressure control scenarios in hydraulic systems such as industrial hydraulic equipment, construction machinery, injection molding machines, CNC machine tools, and heavy-duty machinery

1. Core Technical Specifications

(1) Power Supply Specifications

Input Voltage: 24 V DC ±10% (nominal operating voltage)

Voltage Adaptation Range: 18 V DC ~ 32 V DC (wide voltage compatibility)

Power Consumption: Typical 5 W, Maximum 8 W

Reverse Polarity Protection: Built-in anti-reverse connection circuit, withstands -30 V DC reverse voltage without damage

Surge Protection: Complies with IEC 61000-4-5 standard, ±2 kV differential mode, ±4 kV common mode protection

(2) Input Signal Parameters

Configurable Control Signal Types (via software):

Analog Input: 4–20 mA current signal, 0–10 V DC voltage signal

Digital Input: PWM signal (frequency 100 Hz ~ 1 kHz, duty cycle 0–100% adjustable)

Input Impedance: ≤250 Ω for 4–20 mA signal; ≥100 kΩ for 0–10 V DC signal

Input Resolution: 12-bit (analog signal sampling accuracy)

Signal Response Delay: ≤1 ms (from signal input to module recognition)

(3) Output Control Specifications

Exclusive Output Parameters for 200-510-111-034

Output Type: Proportional solenoid drive current output

Continuous Output Current Range: 0–1.5 A DC

Peak Output Current: 2.5 A DC (duration ≤100 ms)

Current Regulation Accuracy: ±1% full scale (at 25℃ ambient temperature)

Compatible Proportional Valve Models: Bosch Rexroth 4WRPE, 4WREE series proportional pressure valves

Exclusive Output Parameters for 200-510-070-113

Output Type: Proportional solenoid drive current output

Continuous Output Current Range: 0–2.0 A DC

Peak Output Current: 3.0 A DC (duration ≤100 ms)

Current Regulation Accuracy: ±0.8% full scale (at 25℃ ambient temperature)

Compatible Proportional Valve Models: Bosch Rexroth 4WRPH, 4WRZE series high-pressure proportional pressure valves

(4) Control Performance

Pressure Control Accuracy: ±0.5% set pressure (when matched with corresponding proportional valves, within rated working pressure range)

System Response Time: ≤30 ms (from control signal input to hydraulic system pressure stabilization, standard working condition at 25℃)

Control Algorithm: Built-in PID closed-loop control algorithm, supporting parameter self-tuning function

Filter Configuration: Configurable digital low-pass filter, cutoff frequency adjustable from 1–50 Hz

III. Dimensions & Weight

(1) Overall Dimensions (L × W × H, excluding mounting accessories)

200-565-101-013: 85 mm × 60 mm × 45 mm (3.35 in × 2.36 in × 1.77 in)

(2) Mounting Parameters

Mounting Method: Supports panel mounting or 35 mm standard DIN rail mounting (complies with EN 60715 standard)

Mounting Hole Specifications:

200-565-101-013: Mounting hole spacing 65 mm, hole diameter 5 mm

Mounting Torque: Recommended 2.5–3.0 N・m (avoid over-tightening to prevent housing damage)

(3) Weight

200-565-101-013 : Approximately 230 g (0.51 lb)

vmf-IOC16T 200-565-101-013 Vibro-meter
