vmf-cmc16 200-530-111-013 200-530-100-014 Vibro-Meter MODULE BOARD

The ‌Vibro-Meter VMF-CMC16 (200-530-111-013 / 200-530-100-014) Operation Guide‌:

Key Operational Steps‌

1. ‌Hardware Initialization‌

   • ‌Power Up‌: Connect dual-redundant 24V DC (±5%) to PS1+/PS1- and PS2+/PS2- terminals.
   • ‌Network Links‌:
     • Port 1 (ETH1): Primary control network (e.g., DCS)
       Port 2 (ETH2): Engineering/backup network
     • RS485 (Terminals 15-16): Legacy device integration

2. ‌Software Configuration‌

   • Launch ‌VM600 ConfigTool‌ (v4.1 or later).
   • Establish connection via ETH2 or USB service port.
   • Navigate: Hardware Setup → CMC16 → Communication Mapping.

3. ‌Protocol Setup‌

   • ‌Modbus TCP‌: Assign IP address (e.g., 192.168.1.10) and map VM600 registers to holding registers (e.g., 40xxx series).
   • ‌PROFIBUS‌: Set PROFIBUS address via rotary switch and configure GSD file in PLC.
   • ‌Redundancy‌: Enable HSR/PRP for ring topology resilience if applicable.

4. ‌Diagnostic Monitoring‌

   • ‌LED Indicators‌:
     • ‌Green (STATUS)‌: Normal operation
     • ‌Amber (COM ACT)‌: Data traffic detected
     • ‌Red (FAULT)‌: Hardware/configuration error

···········································································································

Our advantages:

1. The brand new product comes with a one-year

comprehensive warranty.

2. All products undergo strict quality inspections.

3. Contact us and our team will provide competitive

quotes and procurement plans.
