VM600 RPS6U PN200-582-500-013 VIBRO-METER

1. Product Identification

Model: VM600 RPS6U
Part No.: PN200-582-500-013
Certification: ATEX II 3G Ex ec IIC T6 Gc, SIL 2 (IEC 61508)

2. Pre-Installation Requirements

2.1 Environmental Limits

2.2 Tools & Materials

• Torque wrench (5-20 Nm range)
• M12x1.5 stainless steel mounting stud
• Dielectric grease (ABB code: GL-7742)

3. Mechanical Installation

Step 1: Mounting

1. Clean mounting surface (Ra ≤3.2µm) 2. Apply thread locker (Loctite 243) to stud 3. Torque to 12 Nm ±1 Nm 4. Verify sensor gap: 0.8-1.2mm to target

Step 2: Alignment

• Use laser alignment tool (ABB AL-55)
• Max misalignment: ±0.5° axial/radial

4. Electrical Connection

4.1 Wiring Diagram

Pin 1: +24V DC (Brown) Pin 2: Signal+ (White) Pin 3: Signal- (Blue) Pin 4: Shield (Drain wire)

4.2 Cable Specifications

• Type: BELDEN 9501 or equivalent
• Shielding: 85% coverage braid + foil
• Max length: 300m (24AWG)

5. Commissioning Procedure

5.1 Power-Up Sequence

1. Apply power while monitoring inrush current (<50mA)
2. Wait 45s for sensor self-test (LED turns green)

5.2 Calibration

• Use ABB Vibration Manager Suite (VMS 5.2+)
• Default parameters:[RPS6U_Config] Sensitivity=100mV/g Bandwidth=2-10000Hz Overload=500g pk

6. Safety & Maintenance

Critical Warnings

• Never disconnect under power (risk of ESD damage)
• Annual recalibration required for SIL 2 compliance
• Replace O-ring (PN200-582-700-005) every 5 years
