MPC4 200-510-111-035 Vibro Meter machinery protection card

MPC4 200-510-111-035 Vibro Meter – Introduction & Technical Specifications
1. Product Introduction
The MPC4 200-510-111-035 Vibro Meter is a high-precision vibration monitoring instrument designed for real-time detection and analysis of mechanical vibration in industrial equipment. It is capable of monitoring key vibration parameters to predict equipment faults, ensure operational safety, and extend the service life of machinery, widely applied in industries such as power generation, petrochemical, metallurgy, and manufacturing.
2. Brand & Model Information
Brand: Vibro Meter
Full Model: MPC4 200-510-111-035
Product Series: MPC4 Series Vibration Monitoring Controllers
Ordering Code: 200-510-111-035
3. General Specifications
Product Type: Digital Vibration Monitoring & Protection Controller
Monitoring Type: Velocity, Acceleration, Displacement (triaxial optional)
Operating Voltage Range: 24 V DC ±15%
Power Consumption: ≤ 8 W (at rated voltage)
Protection Level: IP65 (for external housing); IP20 (for terminal block inside)
Degree of Pollution: Pollution Degree 2 (in accordance with IEC 60664-1)

4. Physical Characteristics
4.1 Weight
Net Weight: Approx. 0.8 kg (main unit only)
Gross Weight (with standard packaging): Approx. 1.5 kg
4.2 Dimensions (W × H × D)
Main Unit Dimensions: 120 mm × 180 mm × 150 mm
Mounting Dimensions: 105 mm × 165 mm (compatible with 35 mm standard DIN rail or panel mounting)
Housing Material: Aluminum alloy (anodized surface treatment)
5. Temperature Parameters
Operating Temperature Range: -30 °C to +75 °C
Storage Temperature Range: -40 °C to +85 °C
Humidity Range: 10% to 90% (non-condensing)
Temperature Drift: ≤ ±0.02% of full scale per °C (within operating temperature range)
6. Input Parameters
6.1 Vibration Sensor Inputs
Number of Input Channels: 4 channels (configurable)
Compatible Sensor Types: Piezoelectric acceleration sensor, eddy current displacement sensor, velocity sensor
Input Signal Range: Acceleration: 0-50 g; Velocity: 0-200 mm/s; Displacement: 0-5 mm (peak-peak)
Input Impedance: ≥ 10 MΩ

Sampling Frequency: Up to 10 kHz per channel
6.2 Auxiliary Inputs
Number of Auxiliary Input Channels: 2 analog input channels (for temperature, pressure, etc.)
Auxiliary Input Signal: 4-20 mA current signal or 0-10 V voltage signal
Input Accuracy: ±0.1% of full scale
7. Output Parameters
7.1 Analog Outputs
Number of Analog Output Channels: 4 channels
Output Signal Type: 4-20 mA current signal (corresponding to measured vibration parameters)
Output Load Resistance: 0-600 Ω
Output Accuracy: ±0.2% of full scale
7.2 Digital Outputs
Number of Digital Output Channels: 8 relay outputs (for alarm and control)
Relay Type: SPDT (Single Pole Double Throw)
Rated Contact Voltage: 250 V AC / 30 V DC
Rated Contact Current: 3 A (resistive load)
Alarm Threshold: Configurable (primary alarm, secondary alarm, trip signal)
