MP3101 TRICONEX

TRICONEX 3101

• Model: TRICONEX 3101 MP3101
• Input Voltage: 24V DC
• Number of Input/Output: Supports up to 32 discrete I/O points
• Communication Protocols: Modbus, Ethernet/IP, etc.
• Operating Temperature Range: -20℃ to 60℃
• Dimensions: 30cm × 20cm × 15cm
• Weight: Approximately 4.5 kg
• Safety Certification: SIL 3

Mport3101R-W

• Model: Mport3101R-W
• Ethernet Port: 1 100M electrical port
• Serial Port: 1 RS232/485 port
• Antenna Interface: 1 2.4GHz antenna interface
• Power Supply: DC 9-36V
• Dimensions: 87.5×36.5×58.7 mm (Excluding the dimensions of buckles and connectors)
• Mounting Method: 35mm standard DIN rail mounting
• Operating Temperature: -40℃ to +75℃
• Storage Temperature: -40℃ to +85℃
• IEC 61000-4-2 (ESD): Level 2 (Contact discharge ±4kV, Air discharge ±15kV)
• IEC 61000-4-4 (EFT): Level 4 (Power supply: differential mode ±4kV; Ethernet port, RS485: ±2kV)
• IEC 61000-4-5 (Surge): Level 4 (Power supply, Ethernet port: differential mode ±2kV; RS485: common mode ±4kV, differential mode ±2kV; Antenna: common mode ±6kV)

MP3101 TRICONEX PDF

MP3101

·······································································································

Our advantages:

1. The brand new product comes with a one-year

comprehensive warranty.

2. All products undergo strict quality inspections.

3. Contact us and our team will provide competitive

quotes and procurement plans.
