B&R X20CP1486 MODULE IN STOCK

1.Model Identification

1. Product model: X20CP1486
2. Product category: Central Processing Unit (CPU) for industrial automation control systems
3. Manufacturer: B&R Industrial Automation

2.Processor Configuration

1. CPU type: 32-bit RISC processor
2. Clock frequency: 1.0 GHz
3. Floating-point  capability: Supported
4. Multi-tasking performance: Preemptive multi-tasking support

3.Memory Specifications

1. RAM (Random Access Memory): 256 MB DDR3 SDRAM
2. Flash Memory: 512 MB (non-volatile, for program storage and data logging)
3. Expandable memory: Support for external SD card (up to 32 GB)
4. Battery backup: Integrated supercapacitor for RAM data retention (up to 72 hours without power)

4.Communication Interfaces

1. Ethernet ports: 2 x 10/100/1000 Mbps RJ45 ports
2. USB interfaces: 1 x USB 2.0 Type A port (for programming and data transfer)
3. Fieldbus interfaces: Native support for POWERLINK (IEC 61158)
4. Additional interfaces: 1 x RS232/RS485 serial port (configurable)

5.Power Supply Requirements

1. Input voltage range: 24 V DC (18 V DC – 32 V DC)
2. Power consumption: Typical 5 W, Maximum 8 W
3. Power supply type: Redundant power supply support (optional)
4. Protection features: Overvoltage protection, reverse polarity protection

6.Operating Environment

1. Operating temperature range: 0 °C to 60 °C (32 °F to 140 °F)
2. Storage temperature range: -25 °C to 85 °C (-13 °F to 185 °F)
3. Relative humidity: 5% to 95% (non-condensing)
4. Altitude: Up to 2000 meters (6562 feet) without derating
5.

7.Mechanical Specifications

1. Housing material: Polycarbonate (PC) and aluminum
2. Installation type: DIN rail mounting (EN 50022, 35 mm)
3. Dimensions (W x H x D): 25 mm x 100 mm x 120 mm (0.98 in x 3.94 in x 4.72 in)
4. Weight: Approx. 300 grams (0.66 lbs)

8.Software & Compatibility

4. Programming software: B&R Automation Studio (Version 4.5 or higher)
5. Supported programming languages: IEC 61131-3 (ST, LD, FBD, IL, CFC), C/C++
6. Firmware update: Support for online firmware updates via Ethernet
7. Compatibility: Compatible with B&R X20 I/O system modules

9.Certification & Compliance

1. Safety certifications: CE, UL, cUL, ATEX (Ex II 3G Ex nA IIC T4 Gc)
2. EMC compliance: EN 55011, EN 55022, EN 61000
3. Industrial standards: IEC 61158, IEC 61010-1, IEC 60068-2

10.Functional Features

1. Real-time performance: Cycle time as low as 1 ms (configurable)
2. Diagnostics: Comprehensive self-diagnostic functions with error logging
3. Security features: Integrated firewall, secure boot, and access control
4. Expansion capability: Support for up to 256 X20 I/O modules via POWERLINK
