3BHE024577R0101 PPC907BE AMC34 ABB Inverter Module

3BHE024577R0101 PPC907BE AMC34 ABB Technical Specifications
1. Brand Information
Brand: ABB
Product Series: PPC907BE Series (Advanced Power Protection Controller)
2. Model Identification
Full Model: 3BHE024577R0101 PPC907BE AMC34
Base Model: PPC907BE
Ordering Code: 3BHE024577R0101
Functional Module: AMC34 (Auxiliary Control Module)
3. General Specifications
Product Type: Digital Power Protection Controller
Application: Designed for protection and control of generators, motors, and other power equipment in industrial power systems
Operating Voltage Range: 110-240 V AC/DC ±10%
Power Consumption: ≤ 15 VA (at rated voltage)
Protection Level: IP20 (when installed in a standard control cabinet)
Degree of Pollution: Pollution Degree 2 (as per IEC 60664-1)

4. Physical Characteristics
4.1 Weight
Net Weight: Approx. 1.2 kg (without accessories)
Gross Weight (with packaging): Approx. 2.0 kg
4.2 Dimensions (W × H × D)
Overall Dimensions: 145 mm × 210 mm × 180 mm
Mounting Dimensions: 130 mm × 190 mm (standard DIN rail mounting compatible, 35 mm DIN rail)
5. Temperature Parameters
Operating Temperature Range: -25 °C to +70 °C
Storage Temperature Range: -40 °C to +85 °C
Humidity Range: 5% to 95% (non-condensing)
Temperature Coefficient: ≤ ±0.01% of reading per °C (within operating temperature range)
6. Input Parameters
6.1 Analog Inputs
Number of Analog Input Channels: 8 differential channels
Input Signal Types: Current (4-20 mA, 0-1 A) / Voltage (0-10 V, ±10 V)
Input Impedance: ≥ 1 MΩ (for voltage inputs); ≤ 0.1 Ω (for current inputs)
Accuracy: ±0.1% of full scale (at 25 °C)
6.2 Digital Inputs
Number of Digital Input Channels: 16 dry contact inputs
Input Voltage: 24 V DC (standard)
Input Current: ≤ 5 mA per channel
Response Time: ≤ 1 ms

7. Output Parameters
7.1 Analog Outputs
Number of Analog Output Channels: 4 channels
Output Signal Types: 4-20 mA (sink/source selectable)
Output Load: 0-500 Ω
Accuracy: ±0.2% of full scale
7.2 Digital Outputs
Number of Digital Output Channels: 12 relay outputs
Relay Type: SPDT (Single Pole Double Throw)
Rated Contact Voltage: 250 V AC / 30 V DC
Rated Contact Current: 5 A (resistive load)
Mechanical Life: ≥ 10^6 operations
Electrical Life: ≥ 10^5 operations (at rated load)
