3500/33 16 Channel Relay Module supply by Bently Nevada

Bently 3500/33 Technical Specifications

1. Brand & Model Information

Brand: Bently Nevada (a GE Measurement & Control brand) Model: 3500/33 Product Category: Machinery Protection System Module

2. Physical Dimensions & Weight

Dimensions (W × H × D): 160 mm × 100 mm × 80 mm (6.30 in × 3.94 in × 3.15 in) Net Weight: 0.8 kg (1.76 lbs) Mounting Type: 3500 Rack-mounted (compatible with Bently 3500 series racks)

3. Core Specifications

Power Supply: 24 V DC ± 10%, Typical Power Consumption: 5 W (max 8 W) Monitoring Channels: 4 independent vibration monitoring channels Measurement Range: Vibration displacement: 0 – 254 μm (0 – 10 mils) pk-pk; Vibration velocity: 0 – 25.4 mm/s (0 – 1.0 in/s) rms Measurement Accuracy: ±1% of full scale Response Time: ≤ 10 ms Communication Protocol: Supports Bently 3500 Rack Communication Bus, compatible with MODBUS TCP/IP (via optional gateway)

4. Temperature Requirements

Operating Temperature Range: -20°C to 65°C (-4°F to 149°F) Storage Temperature Range: -40°C to 85°C (-40°F to 185°F) Humidity Range: 5% to 95% RH (non-condensing)
